Short Course on Electrochemical Migration (ECM), Conductive Anodic Filament (CAF) Formation and Surface Insulation Resistance (SIR) Testing,presented by NACE certified Corrosion Specialist , WebCorr Corrosion Consulting Services.

Electrochemical Migration (ECM), Conductive Anodic Filament (CAF) Formation and Surface Insulation Resistance (SIR) Testing

Course Overview

Corrosion is responsible for more than 50% of microelectronic device failures. Electrochemical corrosion of metallic conductors, electrochemical migration or dendrite growth, and conductive anodic filament (CAF) formation on a printed wiring board can lead to circuit failures. It is important to understand the cause of these failures in order to select materials and processes for soldering and cleaning that will minimize the occurrence of these failures. This course thoroughly and systematically covers the causes and processes of electrochemical migration (ECM), dendrites formation, conductive anodic filament (CAF) formation, their effects on surface insulation resistance (SIR), and the industry standard methods and procedures for SIR testing.

This 1-day course is available for in-house training, online and distance learning worldwide. It can also be customized to meet the specific needs of your organization.

Course Outline

1. Electrochemical Migration (ECM)

1.1 Definition of Electrochemical Migration (ECM)
1.2 ECM Processes and Dendrites Formation
1.3 Reactions on the Anode
1.4 Reactions on the Cathode
1.5 Factors Influencing ECM and Dendrites Formation
1.6 Electrochemical Migration Testing
1.7 Electrochemical Migration (ECM) vs Electromigration (EM)
1.8 Electrochemical Migration Failure Analysis and Prevention

2. Conductive Anodic Filament (CAF) Formation

2.1 Definition of Conductive Anodic Filament (CAF)

2.2 Mechanisms of CAF Formation and Growth

2.3 Factors Influencing CAF Formation
2.3.1 Substrate materials
2.3.2 Conductor configuration
2.3.3 Voltage gradient
2.3.4 Solder flux and HASL fluid
2.3.5 Cleaning
2.3.6 Temperature
2.3.7 Humidity

2.4 Catastrophic Field Failures Due to CAF Formation

2.5 Conductive Anodic Filament vs Dendrite

2.6 VPC-Compass-SE: A Software Tool for the Prediction and Modeling of Corrosion and Electrochemical Migration in Microelectronic Components

3. Effects Surface Insulation Resistance (SIR) Testing

3.1 Definition of Surface Insulation Resistance (SIR)
3.2 Basic Principles of SIR Testing
3.3 The Importance of SIR Testing
3.4 Effects of Electrochemical Migration (ECM) and Conductive Anodic Filament (CAF) on SIR
3.5 SIR Testing: Industry Standards and Test Procedures
3.6 SIR Testing: IPC J-STD-004A vs J-STD-004B
3.7 SIR Testing: Factors Influencing SIR Test Results
3.8 SIR Testing: Hourly vs Daily Readings
3.9 SIR Testing: Pass/Fail Criteria
3.10 Failures During SIR Testing

4. End-of-Course Examination
